94 EasyLine EL3000 Series Commissioning Instructions
Gas Analyzer Start-Up
NOTE
The notes in the sections "ZO23: Gas analyzer start-up (see page 95)"
and "Fidas24: Gas analyzer start-up (see page 96)" must also be
con
sidered for the ZO23 and Fidas24 analyzers.
Starting Up the Gas Analyzer
1 Switch on the power supply of the gas analyzer.
2 The name of the gas analyzer and the number of the software version
are shown in the display while booting.
3 After the start-up phase has ended, the display switches over to the
measured value display.
Example:
4 Check the configuration of the gas analyzer and alter if necessary.
5 After the warm-up phase has ended, the gas analyzer is ready to
carry out measurements.
Duration of the warm-up phase:
Uras26: approx. ½ hour without thermostat, approx. 2 hours with
thermostat
Limas23: approx. 2 hours
Magnos206: approx. 1 hour
Magnos27: approx. 2–4 hours
Caldos27: approx. ½ hour
Fidas24: approx. 2 hours
6 Check the calibration (see page 111) of the gas analyzer.
The ga
s analyzer is calibrated ex works. However, transport stresses
and the pressure and temperature conditions at the installation site
may influence the calibration.
7 Turn on the sample gas supply.
