ABB IRB 2400/16 User Manual

5.2 Calibration methods
Overview
This section specifies the different types of calibration and the calibration methods
that are supplied by ABB.
Types of calibration
Calibration methodDescriptionType of calibration
Calibration PendulumThe calibrated robot is positioned at calibration
position.
Standard calibration
Levelmeter calibration
(alternative method)Standard calibration data is found on the SMB
(serial measurement board) or EIB in the robot.
For robots with RobotWare 5.04 or older, the
calibration data is delivered in a file, calib.cfg,
supplied with the robot at delivery. The file
identifies the correct resolver/motor position
corresponding to the robot home position.
CalibWareBased on standard calibration, and besides
positioning the robot at synchronization posi-
tion, the Absolute accuracy calibration also
compensates for:
• Mechanical tolerances in the robot
structure
• Deflection due to load
Absolute accuracy calibration focuses on pos-
itioning accuracy in the Cartesian coordinate
system for the robot.
Absolute accuracy
calibration (option-
al)
Absolute accuracy calibration data is found
on the SMB (serial measurement board) in the
robot.
For robots with RobotWare 5.05 or older, the
absolute accuracy calibration data is delivered
in a file, absacc.cfg, supplied with the robot at
delivery. The file replaces the calib.cfg file and
identifies motor positions as well as absolute
accuracy compensation parameters.
A robot calibrated with absolute accuracy has
a sticker next to the identification plate of the
robot.
To regain 100% absolute accuracy perform-
ance, the robot must be recalibrated for abso-
lute accuracy!
xx0400001197
Brief description of calibration methods
Calibration Pendulum method
Calibration Pendulum is a standard calibration method for calibration of all ABB
robots (except IRB 6400R, IRB 640, IRB 1400H, and IRB 4400S).
Continues on next page
206 Product manual - IRB 2400
3HAC022031-001 Revision: P
© Copyright 2004-2018 ABB. All rights reserved.
5 Calibration information
5.2 Calibration methods
