3.4.3 Replacement of SMB battery
Note
The battery low alert (38213 Battery charge low) is displayed when the battery
needs to be replaced. The recommendation to avoid an unsynchronized robot
is to keep the power to the controller turned on until the battery is to be replaced.
For an SMB board with 3-pole battery contact (RMU101 3HAC044168-001 or
RMU102 3HAC043904-001), the lifetime of a new battery is typically 36 months.
For an SMB board with 2-pole battery contact, the typical lifetime of a new battery
is 36 months if the robot is powered off 2 days/week or 18 months if the robot is
powered off 16 h/day. The lifetime can be extended for longer production breaks
with a battery shutdown service routine. See Operating manual - IRC5 with
FlexPendant for instructions.
WARNING
See instructions for batteries, Safety risks during handling of batteries on page 38.
Location of SMB battery unit
The SMB battery unit is located inside the robot base, as shown in the figure below.
SMB connectionA
SMB battery RMUB
SMB battery connectorC
Required equipment
Note
There are two variants of SMB units and batteries. One with 2-pole battery contact
and one with 3-pole battery contact. The battery with the 3-pole contact has a
longer lifetime.
It is important that the SMB unit uses the correct battery. Make sure to order the
correct spare parts. Do not replace the battery contact!
NoteSpare part no.Equipment
Lithium battery.3HAC16831-1Battery unit (2-pole battery con-
tact)
This battery requires that the serial
measurement unit 3HAC17396-1 is
installed.
RMU3HAC044075-001Battery unit (3-pole battery con-
tact)
Lithium battery.
Can only be used with SMB unit
3HAC046277-001 containing SMB
board 3HAC044168-001.
Always replace with a new one!3HAC3200-1Gasket, cover
Continues on next page
Product manual - IRB 2400 97
3HAC022031-001 Revision: P
© Copyright 2004-2018 ABB. All rights reserved.
3 Maintenance
3.4.3 Replacement of SMB battery
