ABB IRB 7600 Series User Manual

4 Repair
4.2.3. Mounting instructions for seals
3HAC022033-001 Revision: K250
© Copyright 2004-2011 ABB. All rights reserved.
Flange seals and static seals
The following procedure describes how to fit flange seals and static seals.
O-rings
The following procedure describes how to fit o-rings.
Action
1. Check the flange surfaces. They must be even and free from pores.
It is easy to check flatness using a gauge on the fastened joint (without sealing
compound).
If the flange surfaces are defective, the parts may not be used because leakage could
occur.
2. Clean the surfaces properly in accordance with the recommendations of ABB.
3. Distribute the sealing compound evenly over the surface, preferably with a brush.
4. Tighten the screws evenly when fastening the flange joint.
Action Note
1. Ensure that the correct o-ring size is used.
2. Check the o-ring for surface defects, burrs,
shape accuracy, and so on.
Defective o-rings may not be used.
3. Check the o-ring grooves.
The grooves must be geometrically correct and
should be free of pores and contamination.
Defective o-rings may not be used.
4. Lubricate the o-ring with grease.
5. Tighten the screws evenly while assembling.
Continued
