7 Reference information
7.7. Special tools
4293HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
Tools that may be rented
The following table specifies the tools that may be rented from ABB in order to perform
certain service procedures as described in the Product manual.
The special tools are also listed directly in the instructions.
Guide pins M16 x 250 1 3HAC13120-4
Guide pins M16 x 300 2 3HAC13120-5
Guide pins, sealing ax 2/3, 100mm 1 3HAC14627-3
Guide pins, sealing ax 2/3, 80mm 1 3HAC14627-2
Holder for bits (Stahlwille 736/40 S 5/16") 1 3HAC029090-001
Hydraulic cylinder 1 3HAC11731-1
Hydraulic pump, 80 MPa 1 3HAC13086-1
Hydraulic pump, 150 MPa (Glycerin) 1 3HAC021563-012
Lifting device, base 1 3HAC15560-1
Lifting device, robot 1 3HAC15607-1
Lifting device, upper arm 1 3HAC15536-1
Lifting eye VLBG M12 1 3HAC16131-1
Lifting eye M12 2 3HAC14457-3
Lifting eye M16 2 3HAC14457-4
Lifting tool (chain) 1 3HAC15556-1
Lifting tool, gearbox axis 2 1 3HAC12731-1
Measuring tool 1 6896134-GN
Motor press pinion 1 3HAC021883-001
Oil injector / max 500 MPa 1 3HAC021590-001
Press tool, axis 2 bearing 1 3HAC13453-1
Puller device, axis 2 shaft 1 3HAC021563-001
Press device, axis 2 shaft 1 3HAC021600-001
Press tool, balancing device 1 3HAC020902-001
Press tool, balancing device shaft 1 3HAC17129-1
Puller tool, balancing device shaft 1 3HAC12475-1
Removal tool, wheel unit 1 3HAC15814-1
Support, base 1 3HAC15535-1
Tool set balancing device 1 3HAC15943-1
Description Qty Art. no.
Description Art. no. Note
Lifting tool, lower arm 3HAC14691-1 Includes
• Guidances, 3HAC14445-1
Continued
Continues on next page
