M1M 30 POWER METER USER MANUAL
8.4.Average values (AVG)
AVG represents the average values for instantaneous parameters, calculated over the averaging time (see
AVG sub-menu under ISTL menu), including the following items:
In order to access the AVG values, please press “Enter” when in the parameter page in READ/REAL.
READ REAL
AVG Description
VLN Average phase voltage
VLL Average line voltage
I Average current
IN Average neutral current
P Average per phase active power
Q Average per phase reactive power
S Average per phase apparent power
PQST Average total active, reactive, apparent power
