50 M1M 30 POWER METER USER MANUAL
8.5.Maximum values (MAX)
In order to access the MAX values, please press simultaneously “Enter” and “Up” when in the parameter
page in READ/REAL.
READ REAL +
MAX represents the maximum values for:
MAX Description
VLN Maximum phase voltage
VLL Maximum line voltage
I Maximum current
IN Maximum neutral current
P Maximum average per phase active power calculated over AVG time
Q Maximum average per phase reactive power calculated over AVG time
S Maximum average per phase apparent power calculated over AVG time
PQST Maximum total active, reactive and apparent power
In order to reset all the MAX and MIN values, please press simultaneously “Enter”, “Up” and “Down” when
in any parameter page in READ/REAL.
