2.4 Connection of MConnect
Connection of MConnect boards is similar to
MControl connection.
2.5 Connection of Conventional
feeders
Pin assignments on the control condapter
connectors for conventional feeder modules, valid
for module sizes 6E/4, 6E/2 and ≥ 6E:
Wires for L1/N Wires for +/- 24VDC
X40.1 X40.2 X40.3
X40.4
X10. 1
X10.2
X10.3 X10.4
X40.1
X10.1
12
11 13
14 15
22
25 26 27
21 23
24
31 32 33
34
35 36
37
43
46
41 42 44 45 47
51 54
52 55
53 56
57
61 62
63 64 65
Module control plug connecting to condapter –
view from inside the module
Figure 38 Connection of conventional feeders – pin assignment X40 – X10
