ABB MNS iS System Setup & Operation Quick Guide / System Release 6.0 – Rev.2 / Aug. 2011
6
6
9
9
4 Technical Data
4.1 Control and Communication components
MStart MControl MLink MView
Electrical Data
Auxiliary supply voltage(s)
Supply voltage 24 VDC 24 VDC 24 VDC 24 VDC
Voltage range 19 – 31 VDC 19 – 31 VDC 19 – 31 VDC 19 – 31 VDC
Power consumption
Typical 200 mA 150 mA 1000 mA 1200 mA
Maximum 240 mA 270 mA 1700 mA 1500 mA
Mechanical Data
Dimensions (HxWxD) mm Depending on
starter type
125x53x260 110x265x230 247x185x82
Weight Depending on
starter type
0.7 kg 2.0 kg 5.0 kg
Environmental conditions
Storage temperature -20 …+70°C -20 …+70°C -20 …+70°C - 20 … 60°C
Operation temperature -5 … +55°C -5 … +55°C 0 … +55°C 0 … +40°C *
Degree of protection IP20 IP20 IP20 IP20
* Max. operation temperature for MView display (switchgear room temperature)
Reliability
48 years 19 years MTBF (Meantime between failures)
at 40°C
In combination: 13 years
15 years 8 years
