4.4 Speed measurement
A speed measuring system permits continuous monitoring of the tur-
bocharger speed.
CAUTION
Do not use cables as a climbing aid
If you pull the speed measurement cables too hard, contacts can be
pulled out.
u Do not tension the speed measurement cables.
86505(A)Speed sensor (cable not integ-
rated)
86526F/I converter
86505(B)Speed sensor (cable integrated) 86528Tachometer
86515(A)Cable connector to 86505(A) 01Screw plug
86515(B)Cable connector to 86505(B) 02Gasket
