5-22 Service and Maintenance
HDD Module Installation (for non-HDD SKU only)
Prerequisite:
HDD Door Removal on page 5-12
NOTE: For non-HDD SKU, make sure to use the four screws (included in the package) to
secure the HDD carrier to the HDD.
Figure 5-25. Screws for non-HDD SKU
1. Remove the four (4) screws securing the HDD carrier to the lower case.
Figure 5-26. Removing the Screws
To Next Page
