5-104 Service and Maintenance
LCD Panel Removal
Prerequisite:
LCD Bezel Removal on page 5-100
1. Remove the four (4) screws securing the LCD panel to the LCD cover.
Figure 5-161. Removing the Screws
2. Carefully flip the LCD panel to reveal the eDP cable connector. Then detach the conductive
tape securing the eDP cable from the guides on the bottom of the LCD cover.
Figure 5-162. Removing the LCD Panel
To Next Page
