Acer A315-53G User Manual

6-4 FRU (Field Replaceable Unit) List
3
DC-IN CABLE 45W FOR UMA 50.GP4N2.003
DC-IN CABLE 65W FOR DIS 50.GP5N2.001
4 SPEAKER L+R 23.GY3N2.001
5 IO BOARD FFC CABLE 50.GP4N2.002
6 IO BOARD 55.GP4N2.002
7 Mainboard A315-53_UMACkk_4U Intel i5-7200U UMA LF NB.H2B11.002
8
THERMAL MODULE W/O FAN - DIS 60.GP5N2.001
THERMAL MODULE W/O FAN - UMA 60.GP4N2.004
9 PLASTIC FAN 23.GP4N2.001
10 HDD CABLE 50.H18N2.001
11 HDD BRACKET 33.GY9N2.001
12 LOWER CASE ASSY - BLACK 60.H18N2.001
13 HDD DOOR 42.GY3N2.001
14 RAM DOOR 42.H18N2.001
Table 6-1. Main Assembly Exploded Diagram
No. Description P/N

Acer A315-53G Specifications

General

Processor	Intel Core i5-8250U
Storage	1TB HDD
Operating System	Windows 10 Home
Weight	2.1 kg
Wireless	802.11ac Wi-Fi, Bluetooth 4.0
RAM	DDR4
Battery	2-cell Li-ion battery
Ports	2 x USB 2.0, 1 x USB 3.0, HDMI, Ethernet
Graphics	NVIDIA GeForce MX130 or MX150 with 2 GB of dedicated GDDR5 VRAM
