FRU (Field Replaceable Unit) List 6-11
FRU List
CATEGORY DESCRIPTION PART NO.
BOARD
Foxconn 3rd WiFi 2x2 AGN+ BT4.0 Broadcom
43228+20702 (WiFi 43228 2x2 DB AGN+BT4.0
20702)
NI.23600.100
Foxconn 3rd WiFi 2x2 AGN+ BT4.0 Atheros
WB222
NI.23600.102
Liteon 3rd WiFi 2x2 AGN+ BT4.0 Atheros WB222 NI.23600.103
Liteon 3rd WiFi 2x2 AGN+ BT4.0 Broadcom
43228+20702 (WiFi 43228 2x2 DB AGN+BT4.0
20702)
NC.23611.003
Foxconn Wirelss LAN Atheros HB125 1x1 BGN NI.23600.085
Liteon Wireless LAN Atheros HB125 1x1 BGN NI.23600.086
Foxconn Wirelss LAN Broadcom 4313 IPA 1x1
BGN
NI.23600.090
HDD BOARD 55.SGYN2.001
IO BOARD W/ FFC 55.SGYN2.002
LED BOARD W/ FFC 55.SGYN2.003
CABLE
TP FFC 50.SGYN2.001
DC-IN CABLE 40W 50.SGYN2.002
AC CLIP US 27.WH202.001
AC CLIP EU 27.WH202.002
