Jumper and Connector Locations 3-6
HDD Board View
Figure 3:5. IO Board Jumper
Table 3:5. IO Board Jumper
Item Description
JHDD1 HDD Connector
JHDD2 HDD/B FFC Hot-bar
JHDD2
JHDD1
Top View Bottom View
