Acer Aspire 5610 Series Service Guide

Chapter 3 65
Disassembling the External Modules
Disassembling the HDD Module
1. Remove two screws hodling the HDD bracket on one side.
2. Remove another two screws fastening the HDD bracket on the other side.
3. Detach the HDD from the HDD bracket.
Disassembling the ODD Module
1. Remove the three screws holding the optical bracket.
2. Remove the optical bracket from the optical disk drive.

Acer Aspire 5610 Series Specifications

General

Graphics	Intel GMA 950
Optical Drive	DVD-Super Multi double-layer drive
Wireless	802.11a/b/g
Battery	6-cell Li-ion
Chipset	Mobile Intel 945GM Express
Weight	2.8 kg
RAM	Up to 4 GB DDR2
Storage	120 GB HDD
Display	15.4" WXGA (1280 x 800)
Operating System	Windows XP Home
LAN	10/100 Mbps Ethernet
Ports	4 x USB 2.0, VGA, S-video, headphone/microphone jacks, Ethernet, modem
Processor	Intel Core Duo / Core Solo
