97
KTS Battery Removal
Prerequisite:
EMI Top bracket Removal
1. Disconnect KTS Battery cables (C) from mainboard connector (B). (Figure 3-47)
2. Remove KTS Battery (A) from mainboard.
Figure 3-47. Remove KTS Battery
+ IMPORTANT:
Follow local regulations for battery disposal.
KTS Battery Installation
1. Install KTS Battery (A) to mainboard. (Figure 3-47)
2. Connect KTS Battery cables (C) from mainboard connector (B).
A
B
C
