31
IVEDITI 1707 - 4880981_01
water flow and on the difference of temperature between water entering and air entering. The performances at medium and minimum speed
are obtained by multiplying the values in the graphic by the corrective factors indicated for each speed.
NB: The yield values marked in bold indicate the nominal value.
= Inlet water temperature
= Inlet water temperature with dry bulb
= Heating power yielded
H = maximum speed
= medium speed
L = minimum speed
The heating power yielded indicated in the table must be multiplied by the following corrective factors:
030I 040I 130I 140I 230I 240I 330I 340I 530I 540I 730I 740I 64 102
Thermal power
corrective factors
H 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
0.91 0.91 0.93 0.93 0.91 0.90 0.89 0.91 0.84 0.83 0.83 0.83 0.80 0.88 0.84 0.90
L 0.49 0.60 0.70 0.69 0.75 0.73 0.74 0.76 0.79 0.77 0.73 0.72 0.59 0.71 0.65 0.74
VED040I
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 3558 3374 3189 3010 2831
10 4291 4973 3732 3547
15 4173 3983 3796 3609 3427
60
5 3687 3500 3309 3125 2940
10 3446 3262 3080 2899 2720
15 3309 3125 2940 2756 2574
50
5 2722 2541 2362 2186 2013
10 2597 2415 2233 2054 1876
15 2432 2245 2057 1870 1683
40
5 1881 1705 1532 1356 1185
10 1727 1543 1361 1177 987
15 1498 1294 1048 682 391
VED030I
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 3351 3177 3004 2835 2667
10 4041 4683 3514 3341
15 3930 3751 3575 3398 3227
60
5 3472 3296 3117 2943 2769
10 3246 3072 2901 2730 2561
15 3117 2943 2769 2596 2424
50
5 2564 2393 2224 2059 1895
10 2446 2274 2103 1935 1766
15 2290 2114 1937 1761 1585
40
5 1772 1606 1443 1277 1116
10 1627 1453 1282 1108 929
15 1411 1219 987 642 369
VED140I
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 5974 5665 5355 5054 4754
10 7204 8349 6575 6265 5956
15 7007 6688 6373 6059 5754
60
5 6190 5876 5557 5247 4937
10 5787 5477 5172 4867 4566
15 5557 5247 4937 4627 4322
50
5 4571 4266 3966 3670 3379
10 4360 4055 3750 3449 3149
15 4083 3769 3454 3140 2825
40
5 3158 2863 2572 2276 1990
10 2900 2591 2286 1976 1657
15 2515 2173 1760 1145 657
VED130I
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 5714 5418 5122 4835 4547
10 6891 7986 5993 5696
15 6702 6397 6096 5795 5503
60
5 5921 5620 5315 5019 4722
10 5535 5239 4947 4655 4368
15 5315 5019 4722 4426 4134
50
5 4372 4080 3793 3510 3232
10 4170 3878 3587 3299 3012
15 3905 3605 3304 3003 2702
40
5 3021 2738 2460 2177 1903
10 2774 2478 2186 1890 1585
15 2406 2078 1683 1095
628
