33
IVEDITI 1707 - 4880981_01
VED740I
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 28809 27316 25822 24374 22925
10 34739 40261 31706 30212 28719
15 33788 32249 30733 29217 27746
60
5 29850 28334 26795 25301 23808
10 27904 26410 24939 23468 22020
15 26795 25301 23808 22314 20843
50
5 22043 20572 19123 17697 16294
10 21024 19553 18082 16634 15185
15 19689 18173 16656 15140 13624
40
5 15231 13805 12402 10976 9596
10 13986 12492 11021 9528 7989
15 12130 10478 8487 5522 3168
VED730I
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 26350 24983 23617 22293 20968
10 31773 36823 27633 26267
15 30903 29496 28109 26722 25377
60
5 27302 25915 24507 23141 21775
10 25522 24155 22810 21465 20140
15 24507 23141 21775 20409 19064
50
5 20161 18815 17490 16186 14903
10 19229 17884 16538 15214 13889
15 18008 16621 15234 13847 12461
40
5 13930 12626 11343 10039 8776
10 12792 11426 10080 8714 7307
15 11095 9584 7762 5051 2898
HEATING POWER YIELDED
referred to the maximum speed, based on the water flow and on the difference of temperature between water entering and air entering. The
performances at medium and minimum speed are obtained by multiplying the values in the graphic by the corrective factors indicated for each
speed.
NB: The yield values marked in bold indicate the nominal value.
= Inlet water temperature
= Inlet water temperature with dry bulb
= Heating power yielded
H = maximum speed
= medium speed
L = minimum speed
The heating power yielded indicated in the table must be multiplied by the following corrective factors:
VED030I
BV030
VED130I
BV130
VED230I
BV230
VED330I
BV162
VED532I VED541I VED732I VED741I
Total cooling capacity
corrective values
H 1 1 1 1 1 1 1 1
0.94 0.95 0.93 0.93 0.95 0.96 0.89 0.92
L 0.72 0.78 0.82 0.83 0.79 0.84 0.75 0.82
VE130I
BV130
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 3435 3257 3079 2906 2733
10 4142 4800 3602 3424
15 4028 3845 3664 3483 3308
60
5 3559 3378 3195 3016 2838
10 3327 3149 2973 2798 2625
15 3195 3016 2838 2660 2485
50
5 2628 2453 2280 2110 1943
10 2507 2331 2156 1983 1810
15 2347 2167 1986 1805 1624
40
5 1816 1646 1479 1309 1144
10 1667 1489 1314 1136 952
15 1446 1249 1012 658 378
VED030I
BV030
16 20 22 24
Ph Ph Ph Ph Ph
in dt
[W] [W] [W] [W] [W]
70
5 2017 1913 1808 1707 1605
10 2432 2819 2220 2115 2011
15 2366 2258 2152 2046 1943
60
5 2090 1984 1876 1772 1667
10 1954 1849 1746 1643 1542
15 1876 1772 1667 1562 1459
50
5 1543 1440 1339 1239 1141
10 1472 1369 1266 1165 1063
15 1379 1272 1166 1060 954
40
5 1066 967 868 769 672
10 979 875 772 667 559
15 849 734 594 387 222
