26 34980A Service Guide
2 Specifications
34959A Breadboard Module Specifications and Characteristics
General specifications
Maximum module power
dissipation
6 W
Power available
12 V regulation no load to full load
5 V regulation no load to full load
Maximum power from 12 V
Maximum power from 5 V
10%
5%
6 W
1 W
Relay drives 28, sink up to 100 mA
GPIO ports
Channel 1 and 2 8 configure bits as input or output
Channel 3 3 output bits
Dimensions (L x W x H) 5.4 x 7.5 x 0.9 inches (without PC board)
5.4 x 7.5 x 0.7 inches (with PC board)
