48 Rockwell Automation Publication 2080-UM004C-EN-E - March 2015
Appendix 5 DeviceNet Plug-in – 2080-DNET20
RA_DNET_LDX_ANALOG
This UDFB is used for data exchange with analog CompactBlock I/O.
Module3 INPUT STRING Expansion module 2 I/O configuration.
INPUT X OUTPUT Channels
For example: 16X0 (16 input / 0 Output is physically
present as base module)
Valid String: 32X0, 0X32, 16X0, 0X16, 16X16, 8X8,
8X0, 0X8, 0X6
NOTE: X should always be upper case.
Module4 INPUT STRING Expansion module 3I/O configuration.
INPUT X OUTPUT Channels
For example: 16X0 (16 input / 0 output is physically
present as base module)
Valid String: 32X0, 0X32, 16X0, 0X16, 16X16, 8X8,
8X0, 0X8, 0X6
NOTE: X should always be upper case.
DO_Module1 INPUT UDINT Output data for base module.
DO_Module2 INPUT UDINT Output data for expansion module 1.
DO_Module3 INPUT UDINT Output data for expansion module 2.
DO_Module4 INPUT UDINT Output data for expansion module 3.
FBENO OUTPUT BOOL Function block enable output.
TRUE upon exit.
DI_Module1 OUTPUT UDINT Input data from base module (Module 1).
DI_Module2 OUTPUT UDINT Input data from expansion module 1
(Module 2).
DI_Module3 OUTPUT UDINT Input data from expansion module 2
(Module 3).
DI_Module4 OUTPUT UDINT Input data from expansion module 3
(Module 4).
RA_DNET_LDX_ANALOG: Input and Output Parameters
Variable Name Type Data Type Description
FBEN INPUT BOOL Function block enable input.
TRUE to enable the function.
SlotID INPUT UINT Plug-in slot number (1…5)
NodeID INPUT USINT Slave node address.
Module1
(1)
INPUT STRING Analog base module I/O configuration.
INPUT X OUTPUT Channels
For example: 4X0 (4 input analog module is
physically present as base module)
Valid String: 0X2, 4X0
NOTE: X should always be upper case.
Module2
(1)
INPUT STRING Digital expansion module 1 I/O configuration.
INPUT X OUTPUT Channels
For example: 16X16 (16 input / 16 output is
physically present as expansion module 1)
Valid String: 16X0, 0X16, 16X16, 8X8, 8X0, 0X8, 0X6
NOTE: X should always be upper case.
RA_DNET_LDX_DISCRETE: Input and Output Parameters
Variable Name Type Data Type Description
FBEN
SlotID
NodeID
FBENO
RA_DNET_LDX_ANALOG
AI_CH0
AI_CH1
AI_CH2
AI_CH3
StatusCH0_3
DI_Module2
DI_Module3
Module1
Module2
Module3
AO_Ch0
AO_Ch1
DO_Module2
DO_Module3
