Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 163
Appendix B
Accessories and Dimensions
Product Selection
Catalog Number Description
25B - V 2P5 N 1 0 4
Drive Voltage Rating Rating Enclosure HIM Emission Class Version
PowerFlex 520-Series Drive Ratings
Output Ratings
Input
Voltage Range
Frame
Size
PowerFlex 523 PowerFlex 525Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW Catalog No. Catalog No.
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 85...132 A 25A-V1P6N104
(2)
–
0.5 0.4 0.5 0.4 2.5 85...132 A 25A-V2P5N104 25B-V2P5N104
1.0 0.75 1.0 0.75 4.8 85...132 B 25A-V4P8N104 25B-V4P8N104
1.5 1.1 1.5 1.1 6.0 85...132 B 25A-V6P0N104 25B-V6P0N104
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25A-A1P6N104
(2)
–
0.5 0.4 0.5 0.4 2.5 170...264 A 25A-A2P5N104 25B-A2P5N104
1.0 0.75 1.0 0.75 4.8 170...264 A 25A-A4P8N104 25B-A4P8N104
2.0 1.5 2.0 1.5 8.0 170...264 B 25A-A8P0N104 25B-A8P0N104
3.0 2.2 3.0 2.2 11.0 170...264 B 25A-A011N104 25B-A011N104
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25A-A1P6N114 –
0.5 0.4 0.5 0.4 2.5 170...264 A 25A-A2P5N114 25B-A2P5N114
1.0 0.75 1.0 0.75 4.8 170...264 A 25A-A4P8N114 25B-A4P8N114
2.0 1.5 2.0 1.5 8.0 170...264 B 25A-A8P0N114 25B-A8P0N114
3.0 2.2 3.0 2.2 11.0 170...264 B 25A-A011N114 25B-A011N114
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25A-B1P6N104
(2)
–
0.5 0.4 0.5 0.4 2.5 170...264 A 25A-B2P5N104 25B-B2P5N104
1.0 0.75 1.0 0.75 5.0 170...264 A 25A-B5P0N104 25B-B5P0N104
2.0 1.5 2.0 1.5 8.0 170...264 A 25A-B8P0N104 25B-B8P0N104
3.0 2.2 3.0 2.2 11.0 170...264 A 25A-B011N104 25B-B011N104
5.0 4.0 5.0 4.0 17.5 170...264 B 25A-B017N104 25B-B017N104
7.5 5.5 7.5 5.5 24.0 170...264 C 25A-B024N104 25B-B024N104
10.0 7.5 10.0 7.5 32.2 170...264 D 25A-B032N104 25B-B032N104
15.0 11.0 10.0 7.5 48.3 170...264 E 25A-B048N104 25B-B048N104
20.0 15.0 15.0 11.0 62.1 170...264 E 25A-B062N104 25B-B062N104
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
(1)
0.5 0.4 0.5 0.4 1.4 323...528 A 25A-D1P4N104
(2)
25B-D1P4N104
(2)
1.0 0.75 1.0 0.75 2.3 323...528 A 25A-D2P3N104 25B-D2P3N104
2.0 1.5 2.0 1.5 4.0 323...528 A 25A-D4P0N104 25B-D4P0N104
3.0 2.2 3.0 2.2 6.0 323...528 A 25A-D6P0N104 25B-D6P0N104
5.0 4.0 5.0 4.0 10.5 323...528 B 25A-D010N104 25B-D010N104
