Rockwell Automation Publication 520-UM001G-EN-E - September 2014 55
Chapter 2
Start Up
This chapter describes how to start up the PowerFlex 520-series drive. To simplify
drive setup, the most commonly programmed parameters are organized in a
single Basic Program Group.
Prepare for Drive Start-Up
Drive Startup Task List
1. Disconnect and lock out power to the machine.
2. Verify that AC line power at the disconnect device is within the rated value
of the drive.
3. If replacing a drive, verify the current drive’s catalog number. Verify all
options installed on the drive.
4. Verify that any digital control power is 24 volts.
5. Inspect grounding, wiring, connections, and environmental compatibility.
For information on... See page...
Prepare for Drive Start-Up 55
Display and Control Keys 58
Viewing and Editing Parameters 59
Drive Programming Tools 60
Smart Start-Up with Basic Program Group Parameters 61
LCD Display with QuickView 63
Using the USB Port 63
Read the General Precautions section before proceeding.
ATTENTION: Power must be applied to the drive to perform the following
start-up procedures. Some of the voltages present are at incoming line
potential. To avoid electric shock hazard or damage to equipment, only
qualified service personnel should perform the following procedure.
Thoroughly read and understand the procedure before beginning. If an event
does not occur while performing this procedure, Do Not Proceed. Remove All
Power including user supplied control voltages. User supplied voltages may
exist even when main AC power is not applied to the drive. Correct the
malfunction before continuing.
