1-8 PowerFlex 70 Dimensions
Figure 1.2 PowerFlex 70 IP20/NEMA Type 1 Bottom View Dimensions
Frame Dimensions in millimeters and (inches)
A
B
C
D
42.7 (1.68)
55.4 (2.18)
79.3 (3.12)
85.1 (3.35)
23.9 (0.94)
34.5 (1.36)
86.4 (3.40)
22.2 (0.87) Dia.
4 Places
102.4
(4.03)
129.8
(5.11)
135.9
(5.35)
155.2
(6.11)
163.7
(6.45)
55.6 (2.19)
75.5 (2.97)
85.7 (3.37)
113.5 (4.47)
123.8 (4.87)
127.5 (5.02)
43.4 (1.71)
32.8 (1.29)
101.6
(4.00)
126.2
(4.97)
136.7
(5.38)
155.2
(6.11)
163.7
(6.45)
22.2 (0.87) Dia.
5 Places
36.1 (1.42)
56.1 (2.21)
75.2 (2.96)
94.2 (3.71)
47.7 (1.88)
58.4 (2.30)
112.3 (4.42)
101.3
(3.99)
129.3
(5.09)
155.2
(6.11)
163.5
(6.44)
22.2 (0.87) Dia.
4 Places
37.5 (1.48)
64.0 (2.52)
93.0 (3.66)
121.0 (4.76)
149.7 (5.89)
69.3 (2.73)
58.6 (2.31)
103.2
(4.06)
134.7
(5.30)
155.2
(6.11)
164.1
(6.46)
28.5 (1.12) Dia.
2 Places
22.2 (0.87) Dia.
2 Places
