Analog Outputs 2-21
Analog Outputs Explanation
Each drive has one or more analog outputs that can be used to annunciate a
wide variety of drive operating conditions and values.
The user selects the analog output source by setting [Analog Out Sel].
Configuration
The PowerFlex 70 standard I/O analog output is permanently configured as
a 0-10 volt output. The output has 10 bits of resolution yielding 1024 steps.
The analog output circuit has a maximum 1.3% gain error and a maximum 7
mV offset error. For a step from minimum to maximum value, the output
will be within 0.2% of its final value after 12ms.
The PowerFlex 700 standard I/O analog output is permanently configured
as a 0-10 volt output. The output has 10 bits of resolution yielding 1024
steps. The analog output circuit has a maximum 1.3% gain error and a
maximum 100 mV offset error. For a step from minimum to maximum
value, the output will be within 0.2% of its final value after 12ms.
Absolute (default)
Certain quantities used to drive the analog output are signed, i.e. the
quantity can be both positive and negative. The user has the option of
having the absolute value (value without sign) of these quantities taken
before the scaling occurs. Absolute value is enabled separately for each
analog output via the bitmapped parameter [Anlg Out Absolut].
INPUTS & OUTPUTS
Analog Outputs
342
345
[Analog Out1 Sel]
[Analog Out2 Sel]
Selects the source of the value that
drives the analog output.
Default:
Options:
0 “Output Freq”
See Table
001
002
003
004
005
007
006
012
135
136
137
138
220
219
377
378
Vector
* Vector Control Option Only **Vector firmware 3.001 & later
(1)
Refer to Option Definitions in User Manual..
Options
[Analog Out1 Lo] Value
[Analog Out1 Hi] Value
Param. 341 = Signed Param. 341 = Absolute
0
1
1*
2
3
4
5
6
7
8
9
10
11
12
13
14*
15*
16*
17*
18*
19*
20-23**
24**
“Output Freq”
“Command Freq”
“Command Spd”
“Output Amps”
“Torque Amps”
“Flux Amps”
“Output Power”
“Output Volts”
“DC Bus Volts”
“PI Reference”
(1)
“PI Feedback”
“PI Error”
“PI Output”
“%Motor OL”
“%Drive OL”
“CommandedTrq”
“MtrTrqCurRef”
(1)
“Speed Ref”
“Speed Fdbk”
“Pulse In Ref”
(1)
“Torque Est”
(1)
“Scale Block1-4”
(1)
“Param Cntl”
(1)
–[Maximum Speed]
–[Maximum Speed]
–[Maximum Speed]
0 Amps
–200% Rated
0 Amps
0 kW
0 Volts
0 Volts
–100%
–100%
–100%
–100%
0%
0%
–800% Rated
–200% Rated
–[Maximum Speed]
–[Maximum Speed]
–25200.0 RPM
–800%
0 Hz
0 Hz
0 Hz/RPM
0 Amps
0 Amps
0 Amps
0 kW
0 Volts
0 Volts
0%
0%
0%
0%
0%
0%
0%
0%
0 Hz/RPM
0 Hz/RPM
0 Hz/RPM
0%
+[Maximum Speed]
+[Maximum Speed]
+[Maximum Speed]
200% Rated
200% Rated
200% Rated
200% Rated
120% Rated Input Volts
200% Rated Input Volts
100%
100%
100%
100%
100%
100%
800% Rated
200% Rated
+[Maximum Speed]
+[Maximum Speed]
+[Maximum Speed]
+800%
