Introduction
For More Information
The following table lists publications that provide general drive-related information.
Resource Description
PowerFlex 750-Series AC Drives Technical Data,
publication 750-TD001
Provides detailed information on:
• Drive specifications
• Option specifications
• Fuse and circuit breaker ratings
PowerFlex 750-Series AC Drives Installation Instructions,
publication 750-IN001
Provides detailed information on:
• Drive installation
•Power wiring
•I/O wiring
PowerFlex 750-Series AC Drives Programming Manual,
pub
lication 750-PM001
Provides detailed information on:
• I/O, control, and feedback options
• Parameters and programming
• Faults, alarms, and troubleshooting
PowerFlex 750-Series AC Drives Reference Manual,
publication 750-RM002
Provides detailed information on utilizing specific drive
features in common applications.
Wiring and Grounding Guidelines for Pulse Width
Modulated (PWM) AC Drives Installation Instructions,
publication DRIVES-IN001
Provides the basic information needed to properly install,
protect, wire, and ground pulse width modulated (PWM)
AC drives.
PowerFlex 20-HIM-A6 / -C6S HIM (Human Interface
Modu
le) User Manual, publication 20HIM-UM001
Provides detailed information on HIM components,
operation, and features.
PowerFlex Dynamic Braking Resistor Calculator
Application Technique, publication PFLEX-AT001
Provides detailed information on dynamic braking
components, operation, and features.
PowerFlex 20-750-ENETR Dual-Port EtherNet/IP Option
Module User Manual, publication 750COM-UM008
Provides detailed information on installing, configuring,
using, and troubleshooting the dual-port EtherNet/IP
option module.
PowerFlex 755 Drive Embedded EtherNet/IP Adapter User
Ma
nual, publication 750COM-UM001
Provides detailed information on installing, configuring,
using, and troubleshooting the embedded EtherNet/IP
adapter.
