Accessories and Dimensions B-7
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Table B.J PowerFlex 40 Frames – Ratings are in kW and (HP)
Figure B.1 IP20, NEMA/UL Type Open
Dimensions are in millimeters and (inches).
Weights are in kilograms and (pounds).
Figure B.2 IP30, NEMA/UL Type 1 Option Kit without Communication Option
Product Dimensions
Frame
120V AC –
1-Phase
240V AC –
1-Phase
240V AC –
3-Phase
480V AC –
3-Phase
600V AC –
3-Phase
B 0.4 (0.5)
0.75 (1.0)
1.1 (1.5)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
3.7 (5.0)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
4.0 (5.0)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
4.0 (5.0)
C
(1)
2.2 (3.0) 5.5 (7.5)
7.5 (10.0)
5.5 (7.5)
7.5 (10.0)
11.0 (15.0) 5.5 (7.5)
7.5 (10.0)
11.0 (15.0)
(1)
IP66, NEMA/UL Type 4X rated drives are not availble in Frame C drive ratings.
Frame
ABCDEF
Ship
Weight
B100
(3.94)
180
(7.09)
136
(5.35)
87
(3.43)
168
(6.61)
87.4
(3.44)
2.2
(4.9)
C130
(5.1)
260
(10.2)
180
(7.1)
116
(4.57)
246
(9.7)
–4.3
(9.5)
A
E
B
D
C
F
5.5 (0.22)
33.0
(1.30)
74.3
(2.93)
109.9
(4.33)
64.1 (2.52)
79.1 (3.11)
∅
22.2
(0.87)
25.6 (1.01)
40.6 (1.60)
60.0
(2.36)
111.2
(4.38)
152.2
(5.99)
107.0 (4.21)
66.0 (2.60)
∅
22.2
(0.87)
∅
28.5
(1.12)
24.0 (0.94)
Frame B - 22-JBAB
Frame C - 22-JBAC
22B-UM001.book Page 7 Tuesday, May 30, 2017 5:22 PM
