3-10 Programming and Parameters
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Basic Program Group (continued)
P036 [Start Source] Related Parameter(s): d012, P037
Stop drive before changing this parameter.
Sets the control scheme used to start the drive.
Refer to Start and Speed Reference Control
on page 1-23 for details about how other drive settings
can override the setting of this parameter.
Important: For all settings except option 3, the drive must receive a leading edge from the start input
for the drive to start after a stop input, loss of power or fault condition.
Options 0 “Keypad” (Default) • Integral keypad controls drive operation.
• I/O Terminal 1 “Stop” = coast to stop.
• When active, the Reverse key is also active unless
disabled by A095
[Reverse Disable].
1 “3-Wire” I/O Terminal 1 “Stop” = stop according to the value set in
P037
[Stop Mode].
2 “2-Wire” I/O Terminal 1 “Stop” = coast to stop.
3 “2-W Lvl Sens” Drive will restart after a “Stop” command when:
• Stop is removed
and
• Start is held active
4 “2-W Hi Speed” Important: There is greater potential voltage on the output
terminals when using this option.
• Outputs are kept in a ready-to-run state. The drive will
respond to a “Start” command within 10 ms.
• I/O Terminal 1 “Stop” = coast to stop.
5 “Comm Port” • Remote communications. Refer to Appendix C for details.
• I/O Terminal 1 “Stop” = coast to stop.
6 “Momt FWD/REV” • Drive will start after a momentary input from either the
Run FWD Input (I/O Terminal 02) or the Run REV Input (I/
O Terminal 03).
• I/O Terminal 1 “Stop” = coast to stop.
ATTENTION: Hazard of injury exists due to unintended operation.
When P036 [Start Source] is set to option 3, and the Run input is
maintained, the Run inputs do not need to be toggled after a Stop input for
the drive to run again. A Stop function is provided only when the Stop input
is active (open).
