NX-2200 Specif ications
NX-2200 Specifications
Dimensions (HWD): 1.766" x 17" x 9.12" (44.85mm x 431.8mm x 231.64mm)
RU: 1
Active Power
Requirements:
• DC input voltage (typical): 12 V
DC
• DC current draw: 250 mA @ 12 V
DC
• DC range, voltage: 9-18 V
DC
Active Power
Consumption:
4.2W
Memory: • 512 MB RAM
• 1 MB Non-volatile RAM (NVRAM)
• 8 GB Internal MicroSD memory card
Weight: 6.08 lbs (2.7578 kg)
Enclosure: Metal with black matte finish
Certifications: • FCC CFR Title 47 Part 15
• CE EN 55022
• CE EN 55024
• CE EN 60950-1
•IEC 60950-1
•UL 60950-1
•C-Tick CISPR 22
•IC CISPR 22
•VCCI CISPR 22
• RoHS / WEEE compliant
Front Panel Components:
Program Port: 1 Type-B USB port that can connect to a USB port on a PC and access the NetLinx Studio program for controller
configuration.
USB Port: 1 Type-A USB port for connecting a mass storage device for loading .tkn files, reading or writing configuration
files and log files, or updating the firmware on the unit.
Master LEDs: • LINK/ACT (green): Blinks when the Ethernet cables are connected and terminated correctly. Also blinks when
receiving Ethernet data packets.
• STATUS (green): Blinks to indicate that the system is programmed and communicating properly.
• OUTPUT (red): Blinks when the Controller transmits data, sets channels On and Off, sends data strings, etc.
• INPUT (yellow): Blinks when the Controller receives data from button pushes, strings, commands, channel
levels, etc.
ICSLAN LEDs (red): 1 LED which blinks when the RJ-45 cables to port 1 is connected and terminated correctly. The LED also blinks
when receiving LAN data packets.
Serial LEDs (red): 2 sets of four LEDs, each of which light to indicate that the corresponding RS-232 ports (2-4) and RS-232/422/
485 port (1) are transmitting or receiving RS-232, 422, or 485 data.
Relay (red): 4 LEDs light to indicate the relay channels 1-4 are active (closed). These LEDs reflect the state of the relay on port
21.
IR/Serial (red): 4 LEDs light to indicate the IR/Serial ports 11-14 are transmitting control data. LED indicator for each IR port
remains lit for the length of time that IR/Serial data is being generated.
Digital I/O (yellow): Lights when the I/O channels 1-4 are active. The LED for each I/O port reflects the state of that particular port.
Rear Panel Components:
RS-232/422/485
(Port 1):
1 10-pin RS-232/422/485 control ports using a 10-pin 3.5 mm mini-Phoenix (male) connector with XON/XOFF
(transmit on/transmit off), CTS/RTS (clear to send/ready to send). Supports 300-115,200 baud.
RS-232 (Ports 2-4): 3 5-pin RS-232 control ports using 5-pin 3.5 mm mini-Phoenix (male) connectors with
XON/XOFF (transmit on/transmit off), CTS/RTS (clear to send/ready to send). Supports 300-115,200 baud.
Relay (Port 21): 4 2-pin 4-channel single-pole single-throw relay ports.
Each relay is independently controlled.
Supports up to 4 independent external relay devices
Channel range = 1-4
Each relay can switch up to 24 V
DC
or 28 V
AC
@ 1 A
8-pin 3.5 mm mini-Phoenix (male) connector provides connection to relays
Digital I/O (Port 22): 4-channel binary I/O port for contact closure with each input being capable of voltage sensing. Input format is
software selectable with interactive power sensing for IR ports.
