04_20
In order to carry out horizontal adjustment of the light beam:
•
Rest the vehicle on its stand.
•
Working from the left rear side of the windshield, use a short crosshead
screwdriver on the specific screw (2). SCREW it (clockwise) to move the light
beam to the left; UNDO it (anticlockwise) to move the light beam to the right.
NOTE
CHECK THAT THE LIGHT BEAM HORIZONTAL DIRECTION IS CORRECT.
04_21
Front direction indicators (04_21)
•
Rest the vehicle on its stand.
•
Loosen and remove screw (1).
•
Remove glass (2).
•
Press bulb (3) slightly and turn it anticlockwise.
•
Pull the bulb (3) out of its fitting.
•
Insert a bulb of the same type adequately.
WARNING
IF PARABOLE (4) STICKS OUT OF ITS FITTING, INSERT IT AGAIN PROPERLY.
105
