Fuel reserve
2.5 l (0.55 UK gal; 0.66 US gal)
after refuelling:
•
The fuel cap may only be refitted with the key (2) inserted.
•
Once the key (2) is inserted, press the cap to close it again.
•
Remove the key (2).
•
Close the cover (1).
MAKE SURE THE CAP IS TIGHTLY CLOSED.
03_04
Rear shock absorbers adjustment (03_04, 03_05)
The rear suspension consists of a spring-shock absorber unit linked to the frame via
uniball joints.
To adjust the setting, the shock absorber has one set screw (1) to adjust rebound
damping, a ring nut for spring preloading adjustment (2), a locking ring nut (3) and a
set screw for adjusting compression damping (4).
CAUTION
CARRY OUT MAINTENANCE OPERATIONS AT HALF THE INTERVALS RECOM-
MENDED IF THE VEHICLE IS USED IN WET OR DUSTY AREAS, OFF ROAD OR
FOR SPORTING APPLICATIONS.
CHECK THE REAR SHOCK ABSORBER AND ADJUST, IF NECESSARY.
REAR SHOCK ABSORBER STANDARD SETTING IS ADJUSTED TO MEET TOU-
RIST RIDING.
62
