04_02
04_03
•
Switch off the engine and wait at least five minutes to allow the lubricant to
drain back into the sump.
•
Keep the vehicle upright on a level surface and with both wheels on the
ground.
•
Check the oil level from the sight glass on the clutch case.
MAX = maximum level.
MIN = minimum level
The difference between the "MAX" and "MIN" marks is approx. 460 cm³ (28.07 cu.in).
•
The oil level is correct when it is close to the "MAX" mark.
CAUTION
THE VEHICLE MUST BE UNLOADED.
04_04
Engine oil top-up (04_04)
CAUTION
DO NOT GO BEYOND THE "MAX" AND BELOW THE "MIN" LEVEL MARK TO
AVOID SEVERE ENGINE DAMAGE.
89
