use and maintenance MX 125
16
INSTRUMENTS AND INDICATORS TABLE
Description Function
2 stroke oil reserve
warning light (
)
Comes on, for about 0.5 seconds, whenever the ignition switch is brought to position ≈
∆,
thus testing the correct operation of the bulb.
If the light does not come on in this phase, contact an Concessionario Ufficiale aprilia.
If the warning light comes on during the normal operation of
the engine, this means that the 2 stroke oil reserve is being
used; in this case, provide for topping up, see pag. 37 (2 STROKE OIL TANK).
Neutral indicator warning light
()
It comes on when the gear is in neutral.
Direction indicator
warning light (
()
Blinks when the direction indicators are on.
High beam warning light (
)
Comes on when the headlight is in "high beam" position or when the high beam signalling is
operated.
Low beam warning light (
)
It comes on when the front low beam bulbs are on.
CAUTION
