31
use and maintenance MX 125
MODE
1
DST
RT
SPD
KM/H
11:49:13
1
30:47
0
64
54
0
MODE
MODE
1
64
54
1
74
54
1
54
54
DST
DST
DST
MODE
1 2
DSTODO
AR TT
ASS PD MS
KM/H
LO
88:88:88
88:88
8
888
888
88
88
88
3
3
ALIGNING THE PARTIAL VALUES (TRIP)
The partial distance covered (DST) can be
modified by increasing or decreasing the
value appearing on the display. This
function can be used during competitions
to make the displayed value match the one
relating to the racetrack.
CAUTION
Do not use this function to reset the
value (DST); to reset partial values refer
to page pag. 30 (RESETTING THE
PARTIAL VALUES).
◆
Keep the centre ≈MODE∆ push button
pressed for about 3 seconds.
◆
Press the right push button to increase
the value.
◆
Press the left push button to decrease
the value.
◆
Screen (A), with the changes made, will
be displayed after about 3 seconds.
BACKLIGHTING
◆
Press right push button to enable display
backlighting, The light will be
automatically switched off after 4
seconds.
CHANGING THE BATTERY
◆
Remove headlight fairing.
◆
Loosen the 2 cross-head screws
between instrument holder and metal
plate.
◆
Disconnect the 2-way connector from
speedometer transmission unit.
◆
To remove the digital instrument from its
holder, slightly press on LCD side.
◆
Disconnect the ≈sliding shoe∆ from the
digital instrument body.
◆
Loosen the battery cover cap behind the
digital instrument.
◆
Change the "CR2032" battery.
