Use of a new battery (04_09, 04_10, 04_11)
CHECK THAT THE CABLE TERMINALS AND BATTERY LEADS ARE:
- IN GOOD CONDITION (NOT CORRODED OR COVERED BY DEPOSITS);
- COVERED BY NEUTRAL GREASE OR PETROLEUM JELLY.
CAUTION
UPON REFITTING, CONNECT THE LEAD TO THE POSITIVE TERMINAL (+) FIRST
AND AFTERWARDS THE LEAD TO THE NEGATIVE TERMINAL (-).
04_09
•
If the saddle had been refitted, remove it.
•
Install the battery (6) in its seat.
•
Position the positive cable (5) correctly, and fasten it to the positive terminal
(+), tightening the screw (4).
The positive cable (5) must be positioned to the side of the battery (6).
•
Position the rubber protective cap on the positive terminal (+).
•
Position the negative cable (3) correctly, and fasten it to the negative terminal
(-), tightening the screw (2).
The negative cable (3) must be positioned to the side of the battery (6).
167
