02_104
Switch direction indicators (02_104, 02_105)
Move the switch to the left to indicate a left turn; move the switch to the right to indicate
a right turn. Pressing the switch deactivates the turn indicator.
CAUTION
IF THE TURN SIGNAL INDICATOR LAMP FLASHES RAPIDLY, THIS MEANS
THAN ONE OR BOTH OF THE TURN SIGNAL LED MODULES HAVE FAILED.
02_105
In DRL ON mode, the DRL light on the relative side (left or right) is dimmed automat-
ically when a turn signal is activated (see figure).
The turn indicators have a self-cancelling function that implements the following logic.
With the vehicle at standstill (speed = zero), the turn indicators continue flashing in-
definitely.
With the vehicle in motion, the turn signals self-cancel when one the two following
conditions is met:
•
After a time (t) = 40 sec.
•
After riding 500 m (0.31 mi)
If the vehicle speed reaches zero during this period, the time and distance counts are
reset and start again from zero when the vehicle starts moving once again.
81
