arcelik BEKO K76540NEBWU User Manual

CONFIDENTIAL
25
30” BUILT-IN REFRIGERATOR / REVISION NUMBER: 00
9. U4 BOARD
COMPONENT CONNECTION TABLE
CONNECTOR
PIN
TYPE-22:
220V AC
INPUT
KN5
1
NEUTRAL
KN5
3
PHASE
220V AC
OUTPUT
KN5
5
FRZ DEFROST HEATER
KN5
6
FF HEATER
KN5
7
IONIZER
KN5
8
MAIN WATER VALVE
KN5
9
WATER PIPE HEATER
KN5
10
WATER VALVE
KN5
11
ICE VALVE
220V AC
INPUT
KN5
13
DISPENSER SWITCH
220V AC
OUTPUT
KN7
1
COMPRESSOR(VCC)
DC
INPUT
KN9
1
DC FF DOOR RIGHT +
KN9
2
DC FF DOOR RIGHT -
KN9
3
KN9
4
DC FF DOOR LEFT +
KN9
5
DC FF DOOR LEFT -
KN9
6
DC
OUTPU
KN12
1
5V
