arcelik BEKO K76540NEBWU User Manual

CONFIDENTIAL
8
30” BUILT-IN REFRIGERATOR / REVISION NUMBER: 00
2. PRODUCT OVERVIEW
The existing figure is schematic and may not one-to-one match with the product. The
parts being not relevant to this product belong to other models.
1-Reed Switch Compartment
2-Hinge Cover
3-Hinge
4-Magnetic Upper Cover
5-
Upper Narrow Door Shelf
*6-
Moving Gallon Door Shelf
Optional (Narrow Moving Door Shelf)
7-Lower Narrow Door Shelf
8-Lower Cover
9-Freezer Lower Drawer
10
-Freezer Top Drawer
11
-Ice Box
12
-Icematic
13
-0 Degree Vegetable Bin
14
-Control and Indicator Panel
15
-Upper Vegetable Bin
16
-
Glass Shelf Over Vegetable Bin
17
-Short Glass Shelf
18
-Long Glass Shelf

arcelik BEKO K76540NEBWU Specifications

General

Brand	arcelik
Model	BEKO K76540NEBWU
Category	Refrigerator
Language	English
