Asus Motherboard A8N-SLI Premium User Manual

ASUS A8N-SLI Premium 4-9
3. Select the ASUS FTP site
nearest you to avoid network
traffic, or click Auto Select.
Click Next.
Updating the BIOS through the Internet
To update the BIOS through the Internet:
1. Launch the ASUS Update utility from the Windows
®
desktop by clicking
Start > Programs > ASUS > ASUSUpdate > ASUSUpdate. The ASUS
Update main window appears.
2. Select Update BIOS from
the Internet option from the
drop-down menu, then click
Next.

Asus Motherboard A8N-SLI Premium Specifications

General

Chipset	NVIDIA nForce4 SLI
CPU Socket	Socket 939
Form Factor	ATX
Memory Type	DDR
Memory Slots	4 x DIMM
Max Memory	4 GB
PCI Express x16	2
PCI Express x1	1
PCI Slots	3
USB Ports	10 x USB 2.0
SLI Support	Yes
SATA Ports	4
IDE	2
RAID Support	RAID 0, 1, 0+1
Audio	Realtek ALC850 8-channel
LAN	2 x Gigabit LAN
