ASUS A8N-SLI Premium 4-21
DRAM Configuration
The items in this sub-menu show the DRAM-related information
auto-detected by the BIOS.
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Select Menu
Item Specific Help
Place an artificial memory
clock limit on
the system. Memory is
prevented from
running faster than this
frequency.
DRAM Configuration
DRAM Over 4G Remapping [Disabled]
Max Memclock (MHz) [Auto]
1T/2T Memory Timing [Auto]
CAS# latency (Tcl) [Auto]
RAS# to CAS# delay (Trcd) [Auto]
Min RAS# active time (Tras) [Auto]
Row precharge Time (Trp) [Auto]
Row Cycle Time (Trc) [Auto]
Row Refresh Cycle Time (Trfc) [Auto]
Write Recovery Time (Twr) [Auto]
Read-to-Write Delay (Trwt) [Auto]
Phoenix-Award BIOS CMOS Setup Utility
Advanced
DRAM Over 4G Remapping [Disabled]
Enables or disables DRAM remapping when using 4G of system
memory. Configuration options: [Disabled] [Enabled]
Max Memclock (MHz) [Auto]
Sets the maximum operating memory clock.
Configuration options: [Auto] [DDR200] [DDR266] [DDR333]
[DDR400] [DDR400] [DDR433] [DDR466] [DDR500] [DDR533]
[DDR550] [DDR600]
1T/2T Memory Timing [Auto]
Sets the memory timing. Configuration options: [Auto] [1T] [2T]
CAS# latency (Tcl) [Auto]
Sets the CAS# latency.
Configuration options: [Auto] [2.0] [2.5] [3.0]
RAS# to CAS# delay (Trcd) [Auto]
Sets the RAS# to CAS# delay to Rd/Wr command on the same bank.
Configuration options: [Auto] [2] [3] [4] [5] [6] [7]
