Asus P5Q Deluxe User Manual

4-28 Chapter 4: Software support
4.3.9 ASUS AI Direct Link
ASUS AI Direct Link allows you to form a computer-to-computer network via a
network cable to share les with high transfer rate. You must rst connect two
computers (at least one of them is ASUS product) using a network cable, and then
install the utility to both computers to avail the AI Direct Link feature.
• Turn off your rewall software other than Windows Firewall before launching
AI Direct Link.
• The transfer rate is limited if you use a 10/100 LAN card.
Using AI Direct Link
To enable the incoming folder:
1. From the Windows
®
taskbar, right click on the AI Direct Link icon and
select
Incoming folder > Enable incoming folder
.
2. If you want to to verify the incoming
user, select
Use my account
and
set your username and password.
Otherwise, select
Use public
account
.
For security’s sake, it is
recommended that you set a
username and password.
3. Click
OK
and the “Ready for incoming” message
appears.
To disable the incoming folder, select
Incoming
folder > Disable incoming folder
.
For Windows XP Home
edition users, click Steps of
enabling le sharing on this
pop-up message and follow
the instructions to enable the
incoming folder.

Asus P5Q Deluxe Specifications

General

Chipset	Intel P45
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4 x DIMM
Max Memory	16 GB
Form Factor	ATX
PCI Express x16	2
PCI Express x1	3
PCI Slots	2
SATA Ports	6 x SATA 3Gb/s
IDE Ports	1 x ATA133
Max. LAN Speed	10/100/1000 Mbps
Audio Chipset	ADI AD2000B
RAID Support	RAID 0, 1, 5, 10
USB Ports	12 x USB 2.0
Audio Channels	8-channel
CPU Type	Core 2 Quad / Core 2 Duo / Pentium / Celeron
Back Panel Ports	eSATA, USB, LAN, Audio
Memory Speed	1200/1066/800/667 MHz
eSATA Ports	2 x eSATA 3Gb/s
