ASUS P5Q Deluxe 1-1
1.1 Welcome!
Thank you for buying an ASUS
®
P5Q Deluxe motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
If any of the above items is damaged or missing, contact your retailer.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS P5Q Deluxe
I/O modules 1 x 2-port USB 2.0 and 1-port 1394 (4-pin) module
Cables 2 x 2-port Serial ATA power cables
8 x Serial ATA signal cables
1 x Ultra DMA 133/100/66 cable
1 x Floppy disk drive cable
Accessories 1 x ASUS Q-Shield (I/O shield)
1 x ASUS Q-Connector Kit (USB, 1394, system
panel; Retail version only)
1 x ASUS Optional Fan for Water-Cooling or
Passive-Cooling only
Application DVD ASUS motherboard support DVD
Documentation User guide

Asus P5Q Deluxe Specifications

General

Chipset	Intel P45
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4 x DIMM
Max Memory	16 GB
Form Factor	ATX
PCI Express x16	2
PCI Express x1	3
PCI Slots	2
SATA Ports	6 x SATA 3Gb/s
IDE Ports	1 x ATA133
Max. LAN Speed	10/100/1000 Mbps
Audio Chipset	ADI AD2000B
RAID Support	RAID 0, 1, 5, 10
USB Ports	12 x USB 2.0
Audio Channels	8-channel
CPU Type	Core 2 Quad / Core 2 Duo / Pentium / Celeron
Back Panel Ports	eSATA, USB, LAN, Audio
Memory Speed	1200/1066/800/667 MHz
eSATA Ports	2 x eSATA 3Gb/s
