ASUS P5Q Deluxe 3-15
3.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to congure overclocking-related items.
Take caution when changing the settings of the Ai Tweaker menu items.
Incorrect eld values can cause the system to malfunction.
3.4.1 Ai Overclock Tuner [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal
frequency. Select either one of the preset overclocking conguration options:
Manual Allows you to individually set overclocking parameters.
Auto Loads the optimal settings for the system.
Scroll down to display the following items:
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
NB GTL Reference [Auto]
SB Voltage [Auto]
PCIE SATA Voltage [Auto]
Load-Line Calibration [Auto]
CPU Spread Spectrum [Auto]
PCIE Spread Spectrum [Auto]
Select Screen
Select Item
Enter Go to Sub Screen
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Ai Tweaker Advanced Power Boot Tools Exit
Congure System Performance Settings
Ai Overclock Tuner [Auto]
CPU Ratio Setting [Auto]
FSB Strap to North Bridge [Auto]
DRAM Frequency [Auto]
DRAM Command Rate [Auto]
DRAM Timing Control [Auto]
DRAM Static Read Control [Auto]
Ai Clock Twister [Auto]
Ai Transaction Booster [Auto]
CPU Voltage [Auto]
CPU GTL Voltage Reference(0/2) [Auto]
CPU GTL Voltage Reference(1/3) [Auto]
CPU PLL Voltage [Auto]
FSB Termination Voltage [Auto]
DRAM Voltage [Auto]
NB Voltage [Auto]
3.4.2 CPU Ratio Setting [Auto]
Allows you to adjust the ratio between CPU Core Clock and FSB Frequency. Use
the <+> and <-> keys to adjust the value.
Conguration options: [Auto] [06.0] [07.0] [08.0] [09.0]
The following two items appear only when you set the Ai Overclock Tuner item
to [Manual].
The default values of the following items vary depending on the CPU and
memory modules you install on the motherboard.
Options
Manual
Auto
To Next Page
