ASUS P5Q Deluxe 2-3
2.2.2 Layout contents
Connectors/Jumpers/Slots Page
1. ATX power connectors (24-pin EATXPWR, 8-pin ATX12V) 2-32
2. LGA775 CPU Socket 2-6
3. CPU, chassis, and power fan connectors (4-pin CPU_FAN;
3-pin CHA_FAN1-3; 3-pin PWR_FAN)
2-29
4. DDR2 DIMM slots 2-11
5. CPU / Northbridge overvoltage setting (3-pin OV_CPU; 3-pin
OV_NB)
2-19
6. Chassis intrusion connector (4-1 pin CHASSIS) 2-30
7. Floppy disk drive connector (34-1 pin FLOPPY) 2-23
8. ICH10R Serial ATA connectors [red] (7-pin SATA1-6) 2-25
9. IDE connector (40-1 pin PRI_EIDE) 2-24
10. SIL5723 Serial ATA connectors (7-pin SATA_E1 [orange, port 0];
SATA_E2 [white, port 1]
2-26
11. Clear RTC RAM (3-pin CLRTC) 2-18
12. System panel connector (20-8 pin PANEL) 2-34
13. Power-on and Reset switch 2-20
14. USB connectors (10-1 pin USB78, USB910) 2-27
15. Serial port connector (10-1 pin COM1) 2-30
16. IEEE 1394a port connector (10-1 pin IE1394_2) 2-28
17. Optical drive audio connector (4-pin CD) 2-33
18. Front panel audio connector (10-1 pin AAFP) 2-31
19. Digital audio connector (4-1 pin SPDIF_OUT) 2-33
20. ASUS Express Gate SSD 4-50

Asus P5Q Deluxe Specifications

General

Chipset	Intel P45
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4 x DIMM
Max Memory	16 GB
Form Factor	ATX
PCI Express x16	2
PCI Express x1	3
PCI Slots	2
SATA Ports	6 x SATA 3Gb/s
IDE Ports	1 x ATA133
Max. LAN Speed	10/100/1000 Mbps
Audio Chipset	ADI AD2000B
RAID Support	RAID 0, 1, 5, 10
USB Ports	12 x USB 2.0
Audio Channels	8-channel
CPU Type	Core 2 Quad / Core 2 Duo / Pentium / Celeron
Back Panel Ports	eSATA, USB, LAN, Audio
Memory Speed	1200/1066/800/667 MHz
eSATA Ports	2 x eSATA 3Gb/s
