ASUS P5Q Deluxe 4-43
5. The Drive Xpert icon on the Windows
®
notication area turns gray to indicate that the
Drive Xpert function is disabled.
Normal Mode
Partitioning volumes
You have to partition volumes for the hard drive after Drive Xpert conguration.
To partition volumes:
1. Right-click My Computer on the Windows
®
desktop,
and then select Manage from the pop-up window.
2. Select Disk Management.
Right-click the unallocated
space of the disk, and then
select New Partition.
If the New Partition option
is not available, right-click
Disk item, and then select
Initialize Disk to initialize
the disk.
3. A New Partition Wizard screen appears. Follow the screen instructions to
complete the volume partition.
4. The setup is completed.

Asus P5Q Deluxe Specifications

General

Chipset	Intel P45
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4 x DIMM
Max Memory	16 GB
Form Factor	ATX
PCI Express x16	2
PCI Express x1	3
PCI Slots	2
SATA Ports	6 x SATA 3Gb/s
IDE Ports	1 x ATA133
Max. LAN Speed	10/100/1000 Mbps
Audio Chipset	ADI AD2000B
RAID Support	RAID 0, 1, 5, 10
USB Ports	12 x USB 2.0
Audio Channels	8-channel
CPU Type	Core 2 Quad / Core 2 Duo / Pentium / Celeron
Back Panel Ports	eSATA, USB, LAN, Audio
Memory Speed	1200/1066/800/667 MHz
eSATA Ports	2 x eSATA 3Gb/s
