Asus RT-N15U User Manual

21
Chapter 4: Conguring via the web GUI RT-N15U
4
Conguring via
the web GUI
Note:
• In the Router mode, the router’s IP address is 192.168.1.1.
• In the AP mode, use Device Discovery included in the support CD to nd the router’s IP
address.
Conguring via the web GUI
The router’s web graphics user interface (web GUI) allows you to congure these
features: Network Map and EZQoS Bandwidth Management.
To access the web GUI:
1. Launch a web browser, then key in the router’s IP address. The login page of
the router’s web GUI appears.
2. On the login page, key in the default user name (admin) and password
(admin).
3. From the main page, click the navigation menu or links to congure the various
features of the ASUS Wireless Router.

Asus RT-N15U Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4835 GHz
Interface	LAN, WAN
Input voltage	110 - 240 V
Frequency range	2400 - 24835MHz
Input frequency	50/60 Hz
Dimensions (WxDxH)	145 x 172 x 24 mm
Power requirements	12V DC, 1A
USB ports quantity	1
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	1 Gbit/s
WLAN data transfer rates supported	1, 2, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Supported network protocols	WAN PPPoE, PPTP, L2TP
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
MAC address filtering	-
Antennas quantity	2
Antenna gain level (max)	3 dBi
RJ-11 ports quantity	0
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	12 W
Product color	Black
LED indicators	LAN, Power, USB, WAN

Weight and Dimensions

Depth	172 mm
Width	145 mm
Height	24 mm
Weight	240 g
