Chapter 4: Conguring via the web GUI RT-N15U
Restoring/Saving/Uploading settings
To restore/save/upload the settings:
1. Click Advanced Setting from the navigation menu at the left side of your
screen.
2. Under the Administration menu, click Restore/Save/Upload Setting.
3. Select the tasks that you want to do:
• To restore to the default factory settings, click Restore, and click OK in the
conrmation message.
• To save the current system settings, click Save, and click Save in the le
download window to save the system le in your preferred path.
• To restore previous system settings, click Browse to locate the system le that
you want to restore, then click Upload.

Asus RT-N15U Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4835 GHz
Interface	LAN, WAN
Input voltage	110 - 240 V
Frequency range	2400 - 24835MHz
Input frequency	50/60 Hz
Dimensions (WxDxH)	145 x 172 x 24 mm
Power requirements	12V DC, 1A
USB ports quantity	1
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	1 Gbit/s
WLAN data transfer rates supported	1, 2, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Supported network protocols	WAN PPPoE, PPTP, L2TP
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
MAC address filtering	-
Antennas quantity	2
Antenna gain level (max)	3 dBi
RJ-11 ports quantity	0
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	12 W
Product color	Black
LED indicators	LAN, Power, USB, WAN

Weight and Dimensions

Depth	172 mm
Width	145 mm
Height	24 mm
Weight	240 g
