45
Chapter 6: Troubleshooting RT-N15U
6
Troubleshooting
Troubleshooting
This troubleshooting guide provides solutions to some common problems that
you may encounter while installing or using the ASUS Wireless Router. These
problems require simple troubleshooting that you can perform by yourself. Contact
the ASUS Technical Support if you encounter problems not mentioned in this
chapter.
Problem Action
I cannot access the web GUI
for conguring the router.
1. Launch a web browser, then click Tools >
Internet Options...
2. Under Temporary Internet les, click
Delete Cookies... and Delete Files...
3. Disable the proxy settings of the web
browser.
The client cannot establish a
wireless connection with the
router.
Out of Range:
Put the router closer to the wireless client.
Try to change the channel settings.
Authentication:
Use wired connection to connect to the
router.
Check the wireless security settings.
Press the Restore button at the rear panel
for more than ve seconds.
Cannot nd the router:
Press the Restore button at the rear panel
for more than ve seconds.
Check the setting in the wireless adapter
such as SSID and encryption settings.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus RT-N15U and is the answer not in the manual?

Asus RT-N15U Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Bandwidth2.4835 GHz
InterfaceLAN, WAN
Input voltage110 - 240 V
Frequency range2400 - 24835MHz
Input frequency50/60 Hz
Dimensions (WxDxH)145 x 172 x 24 mm
Power requirements12V DC, 1A
USB ports quantity1
Networking featuresEthernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate1 Gbit/s
WLAN data transfer rates supported1, 2, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Supported network protocolsWAN PPPoE, PPTP, L2TP
Security algorithms128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
MAC address filtering-
Antennas quantity2
Antenna gain level (max)3 dBi
RJ-11 ports quantity0
Ethernet LAN (RJ-45) ports4
Power consumption (typical)12 W
Product colorBlack
LED indicatorsLAN, Power, USB, WAN
Weight and Dimensions IconWeight and Dimensions
Depth172 mm
Width145 mm
Height24 mm
Weight240 g
