Asus RT-N15U User Manual

22
RT-N15U Chapter 4: Conguring via the web GUI
Using the Network Map
Network Map allows you to view the status and congure the connection settings
of the Internet, system, and clients in your network. It enables you to quickly set up
your Wide Area Network (WAN) using the Quick Internet Setup (QIS) feature, or to
quickly set up your Local Area Network (LAN) using the WPS Wizard.
Note: For more details on the WPS Wizard, refer to the section WPS Wizard in Chapter 5 of this
user manual.
To view the status or congure the settings, click any of these icons displayed on
the main page:
Icon Description
Internet status
Click this icon to display information on the Internet
connection status, WAN IP address, DNS, connection type,
and gateway address. From the Internet status screen, use
the Quick Internet Setup (QIS) feature to quickly set up your
WAN.
System status
Click this icon to display information on the SSID,
authentication and encryption methods, LAN IP, MAC
address, or turn the wireless radio on/off. Enable the WPS
mode from the System status screen.
Client status
Click this icon to display information about the clients or
computers in the network, and allows you to block/unblock
a client.

Asus RT-N15U Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4835 GHz
Interface	LAN, WAN
Input voltage	110 - 240 V
Frequency range	2400 - 24835MHz
Input frequency	50/60 Hz
Dimensions (WxDxH)	145 x 172 x 24 mm
Power requirements	12V DC, 1A
USB ports quantity	1
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	1 Gbit/s
WLAN data transfer rates supported	1, 2, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Supported network protocols	WAN PPPoE, PPTP, L2TP
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
MAC address filtering	-
Antennas quantity	2
Antenna gain level (max)	3 dBi
RJ-11 ports quantity	0
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	12 W
Product color	Black
LED indicators	LAN, Power, USB, WAN

Weight and Dimensions

Depth	172 mm
Width	145 mm
Height	24 mm
Weight	240 g
