Asus RT-N15U User Manual

9
Chapter 1: Knowing your wireless router RT-N15U
Rear panel
Item Description
1
Power switch
Press this button to turn the power on/off.
2
Power (DC-In) port
Insert the AC adapter into this port to connect your router to a
power source.
3
WAN port
Connect an RJ-45 Ethernet cable to this port to establish WAN
connection.
4
LAN 1 ~ 4 ports
Connect RJ-45 Ethernet cables to these ports to establish LAN
connection.
5
WPS button
Press this button to establish wireless connection.
6
USB 2.0 port
Insert a USB device into this port.
WPS
6
3
4
2
1
5

Asus RT-N15U Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4835 GHz
Interface	LAN, WAN
Input voltage	110 - 240 V
Frequency range	2400 - 24835MHz
Input frequency	50/60 Hz
Dimensions (WxDxH)	145 x 172 x 24 mm
Power requirements	12V DC, 1A
USB ports quantity	1
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	1 Gbit/s
WLAN data transfer rates supported	1, 2, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Supported network protocols	WAN PPPoE, PPTP, L2TP
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
MAC address filtering	-
Antennas quantity	2
Antenna gain level (max)	3 dBi
RJ-11 ports quantity	0
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	12 W
Product color	Black
LED indicators	LAN, Power, USB, WAN

Weight and Dimensions

Depth	172 mm
Width	145 mm
Height	24 mm
Weight	240 g
